The new generation RTS Level is a 1-axis full 360 degree high precision level for ROV’s and Divers. The Level 360 can measure both vertical and horizontal planes. By utilizing technology from the RTS TEXT subsea display the unit delivers unparalleled visibility and is capable of 70+ hours of continous subsea operation per charge cycle. […]
The RADius 700X long-range transponder is a part of the short-distance relative positioning system RADius for use in applications where the need for a robust and highly accurate relative positioning system is crucial. The system comprises an interrogator – typically installed on a vessel – operating in the GHz maritime band and transponders that are […]
The RADius 550X transponder is a part of the short-distance relative positioning system RADius, developed for use in applications where the need for a robust and highly accurate relative positioning system is crucial. The system comprises an interrogator, installed on a vessel, operating in the 5.5 GHz band and transponders that are deployed on the […]
The MetStab XL has the same high precision interface solution as the MetStab but with an increased diameter which allows for larger and heavier modules to be integrated without compromising the accuracy of the stab. The male and female stab can be easily locked and unlocked using the ROV handle. The MetStabXL allows for very […]
The Gas sampler delivered with transparent measuring pipe to decide leak rate and one sampling bottle for recovery of gas samples to the surface. This sampler unit is hydraulic operated by the ROV.
The RTS IRIS is a cutting edge 4K HD subsea camera rated to 6000 meter water depth. It provides the user with exceptional quality video or images in up to 4K resolution. In addition to superior optics, IRIS is delivered in a robust titanium housing and can be utilized on a wide range of subsea […]
Float collar for the cNODE Maxi Transponder
Float collar for the cNODE miniS Transponder
The Naxy Hydrophone can be used for a number of subsea applications, ranging from Oceanography & Marine research to monitoring of the safety in ports and harbors. The Naxys Ehyd is easy to use, has Ethernet interface through a Cat5 cable and the data is stored as .wav files. The user can for instance define […]
The 10,000psi Fully Proportional Injection System (FPIS) has been designed specifically for pressure testing applications on subsea manifolds. The 6-Output Station is a fully isolated media pumping unit which allows the user to be able to supply a separate media at varying flows up to 8.7 lmin and varying pressures from 0- 10,000 psi (690 […]
Our Valve Packs were designed on the back of our growing demand for quality, reliable products for upgrading our ROV systems. These compact lightweight products can be tailored to the individual needs of any application. The units can be built with on / off solenoid valves, proportional or mixture of valve configurations to suit the […]
This unit is used to give pre-dive surface confirmation of the torque tool calibration. It consist of a standard IOS class 1-4 torque reaction bucket with sturdy based and built in torque sensor. The unit comes complete with USB cable to connect to the Torque Tool Control System for Auto Calibration.
The Torque Tool Control System allows the user, from the surface, to adjust the torque and speed. This system is particulary suitable for deepwater operations where torque required for a particular operation may be uncertain, or has multiple values for different operations on the same dive. The actual torque and speed is user controlled and […]
The Manual Torque Tool is designed to allow the ROV manipulator operation of API 17D, ISO 13628-8 Class 1-4 rotary torque interfaces. The tool limits the torque that can be transmitted from the ROV manipulator to the valve stem during an ROV intervention operation, mitigating against the possibility of excessive torque being applied, ensuring damage […]
This torque tool has been specifically developed to provide the highest level of performance using a high specification motor and robust gearbox in an efficient, low weight assembly. The socket is specially profiled for easy alignment. A range of control accessories is available including a precision surface torque verification unit for pre-dive testing. The tool […]
Available for rental from ROVQUIP we have the Forum Subsea torque tool. It has been specifically developed to provide the highest level of per- formance. It has integral torque and turns counting sensors for closed loop control. When matched with a torque tool control manifold, it can provide precise feedback on torque response of any […]
The Forum Subsea FLOT tool is designed to operate in conjunction with a torque tool and is used to orientate and guide flying leads into the stab plate connections. The FLOT tool is designed to take the FORUM Class 1-4 torque tool but can easily accommodate similar tools from other manufacturers. A rotary actuator allows […]
The ROVQUIP tracked skid is the ultimate tool for ultra-shallow water survey and manipulator operations. With a few simple connections the WROV goes from free swimming to tracked mode allowing the ROV to work on the seabed through currents where ‘free flying’ isn’t possible. The skid comes equipped with a dedicated 10 station valve pack […]
The ROVQUIP ROV Tooling Skid is suitable for connection to most work class ROV’s. The pin configuration is to fit the Forum XLX & UHD ROV systems as standard. The Skid is constructed from a lightweight aluminum frame and has been designed to maximize available space whilst still providing positive buoyancy. It is protected with […]
The ROVQUIP HRS Hydrate remediation skid was developed to offer a 4-stage solution to Hydrate Remediation Operations. The system can switch between: Methanol Injection up to 10,000 psi Heat Injection 50 – 60 degrees above ambient High pressure heat jetting 3,000 psi De-Pressurisation operations The system has proven itself successfully in field operations The heat […]
The ROVQUIP BOPSS Tooling Skid is suitable for connection to most work class ROV’s. The pin configuration is to fit the Triton XLX ROV as standard but can be adapted to any other work class ROV. The BOP Shutdown Skid was designed to deliver a tool and the necessary fluid required to deliver high flow […]
The Low-Pressure Water Jetting System is a cost effective, reliable solution based around a Hypro water pump. It has a maximum flow of 435 LPM. It can also be used to control the flow of soft fluid reservoirs.
The Dynaset HPW high pressure water pump transforms the hydraulic power of a work machine effectively into high pressure water power. Small size, light weight and durable construction make the HPW pump very cost effective. The HPW pump is an excellent tool in daily cleaning work and other works, where reliable high pressure water is […]
The ISO Docking Frame is mounted to the front of an ROV by bolting the supplied frame brackets to the front table of the ROV system. The frame comes with 2 x ISO docking latches and operational hoses to connect to the ROV valve pack. Specific interface requirements can be made available if discussed during […]
The Topside Fluid Transfer Pump is an air powered, low pressure, high flow pump that provides a means of fluid transfer for topside operations. The pump is a versatile unit that can be used for numerous operations, for example, priming the reservoirs on an ROV skid. The pump is designed to handle a variety of […]
The Gasket Removal Tool is designed to remove and replace the AX and VX type gaskets inside the wellhead. The tool is positioned in the wellhead with the ROV manipulators and the piston is actuated, extending the shoes to the inner wall of the gasket. The hydraulic pressure from the cylinder and textured face of […]
The Hydraulic Ball Valve utilises a hydraulic cylinder to open and close the ball valve fitted to the tool. This allows the valve to be operated remotely without the ROV manipulators. These are commonly used for pressure testing applications. The standard valve comes with 4 JIC fittings, 1/4” NPT Female thread, however, different sizes of […]
The HP690 features a unique integrated safety circuit that automatically bleeds excess pressure caused by surfacing or temperature variation back to tank.
The ROVQUIP standard ROV Tooling Skid is suitable for connection to most work class ROV’s. The pin configuration is to fit the Triton XLX ROV as standard but can be adapted to any other work class ROV. The Fluid Injection Skid is designed for various pressure testing and fluid injection applications subsea. It comes with […]
The ROVQUIP standard ROV Tooling Skid is suitable for connection to most work class ROV’s. The pin configuration is to fit the Triton XLX ROV as standard but can be adapted to any other work class ROV. The Methanol Injection system has been designed to inject Methanol at high pressure subsea via a client provided […]
The 10,000psi Fully Proportional Injection System (FPIS) has been designed specifically for pressure testing applications on subsea manifolds. The 6-Output Station is a fully isolated media pumping unit which allows the user to be able to supply a separate media at varying flows up to 8.7 l/min and varying pressures from 0 – 10.000 psi […]
The 100 L/min Dirty Work Pack (RQ-083) is designed to protect the hydraulic circuit of the ROV against external contamination during fluid transfer operations. It utilises a hydraulic motor powered by the ROV hydraulic circuit to drive a pump which supplies the delivery fluid from an external compensated reservoir. This configuration isolates the ROV hydraulic […]
The 120 L/min Dirty Work Pack (RQ-071) is designed to protect the hydraulic circuit of the ROV against external contamination during fluid transfer operations. It utilises a hydraulic motor powered by the ROV hydraulic circuit to drive a pump which supplies the delivery fluid from an external compensated reservoir. This configuration isolates the ROV hydraulic […]
The compensators are designed to have a small footprint with ease for mounting. With built in Heli-coils on each side of the main body the compensator can be mounted without any additional bracketry. They are designed to provide submerged vehicles with a positive pressure of incompressible fluid to protect them against seawater ingress. Built with […]
Suitable for handling large and heavy sheets, such as glass and metal, with a flat or slightly concave surface.
ROVQUIP Fluid Reservoir Bladders are made from fabric reinforced, high strength rubber and can used in a wide variety of subsea tasks. They are a cost-effective solution to handling fluid operations subsea. Our reservoir bladders can be made to fit a specific skid gap, or we can provide a range of standard reservoir sizes to […]
The 10,000psi IHPU is a versatile tool that can be used for numerous subsea applications including; Operating BOP Tooling, Transferring Media and Pressure Testing. The output pressure is directly proportional to the output pressure. This allows the output to be adjusted from 0 – 10,000 psi (~690 Bar). The pump can be connected to any […]
The Piston Reservoir provides fluid storage for the operation of other pieces of ROV tooling equipment on board an ROV Skid. The Piston Reservoir operates in a similar manner to a double-acting cylinder. When the reservoir is full of delivery fluid, the piston is fully retracted. As the reservoir begins to deliver fluid, seawater is […]
The ICS 890 Series hydraulic power cutting system offers the superior strength of FORCE4® technology. From the redesigned, more durable rear handle, to the easy to replace drive sprocket, this power cutter is engineered to stand up to your toughest jobs. The flush version cuts within 3/16” of a wall or floor. This package exceeds industry […]
The manipulator mounted Diamond Wire Saw is a lightweight easy deployed cutting tool. The tool is designed for mounting onto a Rigmaster manipulator using the wrist bolts for quick installation. This also means the tool can be stowed when not in use. During cutting operations, the Jaws are used to secure the ROV to the […]
The manipulator mounted cutter comes with a 14” Tungsten Carbide saw blade. The tool is designed for mounting onto a Rigmaster manipulator using the wrist bolts for quick installation. During cutting operations, the Jaws are used to secure the ROV to the cut and once secure the motor starts by spinning the blade before actuating […]
The 17” Rotary Cutter uses strong Steel jaws to securely clamp on to various structures and cut material from a minimum of 10 inches and up to a maximum of 17 inches in diameter (Slight tool modifications can be conducted for larger cuts). The jaws are actuated by two hydraulic rams and are adjustable over […]
The Rotary Brush Cleaning Tool is an ROV operated motorised brush designed to clean out 12 ½ inch subsea wellheads. The rotary brush is driven by a hydraulic motor capable of reaching speeds of up to 400 rpm. The motor is also bi-directional can rotate clockwise and counter-clockwise. A case drain port on the hydraulic […]
The Softsling Hook is designed to ease handling of softslings with ROV and is especially handy when handling slings around pipelines, structures etc. on the seabed.
The RTS knife is designed for cutting ropes, softslings etc. without having to us hydraulic cutters. The knife comes with a fishtail handle as standard but other handles can fitted on request.
The ROV based super grinder is designed for effective and precise cutting. Blades for both steel and concrete is available on request. Our grinders are supplied as standard with special coarse blades with longer life span than normal blades.
The RTS MetSTAB Metrology Stab has been designed based on years of experience with different mechanical subsea interfacing solutions. The unit features unrivaled mating precision and repeatability to ensure objects or subsea equipment is placed correctly in all axes. A special ROV- or diver-operable locking mechanism ensures vertical locking of the male stab during critical […]
The RTS NEMO Subsea Navigator is a combined INS and DVL solution for water depths up to 4000m. The unit is purpose-built for ROV navigation and features state-of-the-art field proven components from renowned subsea manufacturers iXblue, Nortek and RTS. NEMO has been designed for maximum reliability with such features as maintenance-free power drop-out protection, titanium […]
The RTS AXIS is a high-accuracy subsea pitch and roll sensor. The unit provides an absolute accuracy of 0,1 degrees from -45 to +45 degrees across both axis with exceptional repeatability. This makes the RTS AXIS an excellent choice for checks and verifications during subsea inspection and construction work. The 4000 meter rated titanium housing, […]
RTS and Invento Team have developed an ROV bracket for R2Sonic 2024 sonar systems. The purpose of the design is to reduce mobilization time and mounting errors, as well as providing added protection for a key component in an ROV survey spread. The unit also features protected predetermined cable paths, minimal mounting points and a […]
The DVL 1000 is the world’s smallest survey grade DVL. It combines compact design with unprecedented functionality, being able to fly higher in the water column and closer to the seabed than similar equipment. It has a maximum operational depth of 4000 m and is ideally suited for subsea navigation where size and weight are […]
The 720is is the latest generation from Tritech’s renowned multibeam sonar range and offers a real-time, high frequency imaging solution. The Gemini 720is operates at 720kHz and this combined with Tritech’s state-of-the-art processing electronics, produces images of superb clarity. This latest design is ideal for pan and tilt mounting on observation class ROVs. With a […]
Syrinx is a 600 kHz Doppler Velocity Log (DVL) for surface and subsea vehicles. It combines the high altitude, high resolution features of 300 kHz and 1200 kHz DVLs in a single, easy to install navigation instrument. The adaptive bottom lock technology inside Syrinx provides consistency and reliability over challenging and changing topography and works […]
Micro Compatt 6 is our smallest ever LBL transponder. Designed for short duration missions such as spoolpiece metrology or dynamic mobile mapping, Micro Compatt 6 is perfect for installation on Inspection-class ROVs where payload is limited. Its small size also means that a Work-class ROV can deploy multiple units in one trip to the seabed […]
Surveyor’s independent Operator Station for HiPAP. APOS Survey has been developed to provide a cost effective solution for subsea survey and construction operations, making it possible for the surveyor to utilise a vessel’s HiPAP system. Acoustic interrogations are interleaved or run simultaneously with the DP system updates, without making changes to the vessel’s APOS software […]
The Super ZipJet incorporates many technical advances over the previous generation of ROV suction and jetting systems. Considerable emphasis has been placed on increasing efficiency in both the suction and jetting modes. The Super ZipJet incorporates several design features, which improve its reliability and substantially reduce its maintenance costs. Also, it will not block or jam because there are no […]
The new 35 – 60 h.p. Merlin excavation pump is the must have successor to the Excalibur. Merlin incorporates many of the improved design features introduced on the small Super ZipJet pump which has proven to be so successful. The pump is smaller, lighter and more robust with greater performance in both excavation and jetting functions. It features the same […]
FlexiClean is a highly efficient patent-applied-for ROV-deployed cleaning tool that quickly removes marine growth and debris on underwater structures and equipment. It rapidly and gently removes soft marine growth, mussels, barnacles and coral while leaving sensitive surfaces such as paint, plastic sheathing or even duct tape unharmed.
The HLK-4600 Camera Boom Arm has been designed for pipeline inspection work. Using a pair of these arms, pipelines of up to 36” can be easily inspected. Its unique design allows the camera mount to stay at the same angle through the entire 120° of angular movement of the arm, without any adjustment. The camera mount can be tilted […]
The Tritech AnchorZip 10 is a unique product which has been developed using the highly successful ZipPump and ZipJet technologies. The AnchorZip 10 is a heavy duty suction anchorpump designed for workclass vehicles able to produce 25hp of hydraulic power. The AZ10 will offer a very quick and cost effective way of installing and removing suction anchors. Output pressures may […]
The Stanley IW12 is a medium duty ¾” square drive impact wrench designed for underwater bolting and drilling applications. Powered by a Stanley integral Hyrevz motor, the IW12 has a durable swing hammer impact mechanism with adjustable impact intensity from 250 to 1200 ft lbs (340 to 1632 Nm) of torque. Designed to run from a wide range of hydraulic […]
The GR29 is a rotary Grinder/Cutter/Buffer capable of using discs up to 9” Diameter. The system is supplied with a tooling control block and hoses for connection to the ROV. The unit is also supplied with an adaptor plate that will allow the fitting of 6”, 8” & 12” hard nylon brushes for hub cleaning and marine growth removal.
The WCS75HDZ cutter is designed with a fully retractable anvil allowing for simplified cutting of continuous lengths of wire rope.
The WCOS38DLP is a low pressure heavy duty wire rope cutter designed for subsea deployment in severe working conditions.
The RCV155 is primarily intended for use on steel wire rope, having a maximum tensile strength of 1880N/mm and will cut ropes up to 155mm diameter. It may be used on alternative materials, such as electrical power or communication cables, again up to a maximum of 155mm diameter. Where smaller diameters are to be cut, effort should be made […]
The RCV135 is intended for use on steel wire rope having a maximum tensile strength of 1770N/mm and will cut ropes up to 135mm diameter. It may be used on alternative materials, such as electrical power or communication cables, again up to a maximum of 135mm diameter. Where smaller diameters are to be cut, every effort should be made […]
The RCV115 is primarily intended for use on steel wire rope, having a maximum tensile strength of 1880N/mm and will cut ropes up to 115mm diameter. It may be used on alternative materials, such as electrical power or communication cables, again up to a maximum of 115mm diameter. Where smaller diameters are to be cut, effort should be made […]
The RCO54 is a double acting tool primarily intended for use on steel wire rope, having a maximum tensile strength of 1960N/mm, up to 54mm diameter. It may be used on alternative materials, such as electrical power or communication cables, again up to a maximum of 54mm diameter.
The Webtool 38mm cutter is a hydraulically operated, double acting wire cutter. The RCO40LP can cut wire rope with a minimum 25mm diameter, maximum tensile strength of 1960N/mm up to a maximum 38.1mm diameter with a maximum tensile strength of 1960N/mm. It can also be used to cut cables of similar material, such as electrical […]
The SL135 softline cutter is a double acting tool suitable for cutting softlines and ropes up to 127mm (5”) in diameter. It requires a dual line hydraulic supply for operation and is suitable for use subsea.
The SL80 softline cutter is a double acting tool suitable for cutting softlines and dyneema /aramid ropes up to 80mm (3 1/8”) diameter.
The SL55 Softline cutter is a double acting tool suitable for cutting softlines and ropes up to 55mm (2.165”) in diameter.
The cutter is intended for use on Coflexip type riser and will cut hose up to 270mm diameter. It may be used on alternative materials, such as electrical power or communication cables, up to a maximum of 200mm diameter. Where small diameters are to be cut, effort should be made to place the material centrally along the anvil to minimise […]
The HCV100 is a lightweight double acting cutting tool primarily intended for use on umbilical cable and hose and will cut up to 100mm diameter. It may be used on alternative materials, such as electrical power or communication cables, again up to a maximum of 100mm diameter. It may be mounted on an ROV or manipulator arm. Where small […]
The Schilling T4 manipulator is widely regarded as the industry’s premier system that offers the optimum combination of dexterity and strength required to perform fine movements and more complex tasks. Hundreds of TITAN manipulators are in use worldwide every day, and are the predominant manipulator of choice for work-class ROV systems. Constructed mostly from titanium, the T4 is uniquely […]
This manipulator has been designed to lift heavy loads, while being lightweight and easy to control. The Schilling ATLAS arm has six degrees of freedom and a high lift capacity (250kg at full extension). The ATLAS provides operators with the freedom and strength to perform a wider range of heavy duty tasks in harsh subsea […]
1000 Series Mini Beacons incorporate Applied Acoustics’ proprietary Sigma acoustic protocols, proven for use with AAE’s USBL tracking systems, other manufacturers’ USBL systems operating with wide bandwidth transmissions, as well as those using ‘narrow band’ tone signaling. With an industry standard 5-pin connector, the beacons are quick and easy to configure using the 1082 […]
The RTS SiLOG is a compact high spesification data logger, tailor-made for Subsea applications. Based on years of experience with a host different subsea sensors, the RTS Development team has engineered a versatile unit which can not only collect and provide safe data Storage Subsea, it also offers sensor Control through different comms options and […]
The SeaBat T50-P is fully frequency agile from 190 to 420 kHz, allowing for improved swath performace and reduced survey time under difficult conditions. The SeaBat T50-P is designed for fast mobilization on smaller vessels.
The 1082 Smart Switch is a pocket-sized solution to quick and easy 1000 Series beacon configuration, fast charge activation and fast charge monitoring. Easy to operate with 4 buttons and a backlit display, the 1082 Smart Switch also features compatible beacon trickle charge and responder test functionality.
Kongsberg Maritimes cNODE MiniS Transponder, the most advanced HiPAP mini SSBL and LBL transponder developed to date. The cNODE MiniS, with an impressive range of features, 500+ Cymbal digital acoustic channels and backwards compatability, supercedes the Mini MST. The Kongsberg Maritimes cNODE® MiniS transponders are used with HiPAP®, cPAP® and μPAP® systems in underwater positioning […]
The popular GP340 radio is an excellent and unobtrusive way of keeping the team in contact. Streamlining operations with radio communication increases productivity and can form part of an organisation’s health and safety system which is particularly important for individuals who work alone or remote from the team. The GP340 Ex is built with a […]
cNODE® is a new family of transponders for underwater acoustic positioning and data link. They have more than 100 channels available, and can all be positioned by HiPAP® underwater positioning systems. Each underwater target to be positioned must have a transponder or a responder installed. The transponder operates acoustically while the responder requires a cable […]
The RTS CUBE SDM is a self-contained monitoring solution for subsea structures. It is used during the deployment and installation phase but can also be utilized for long-term monitoring to ensure structure stability and position. In addition to monitoring heading, deflection and suction can pressure, the system can also provide the user with live video […]
Lodestar GyroUSBL combines a Sonardyne 6th (6G®) generation high performance HPT USBL transceiver and a Lodestar Attitude and Heading Reference System (AHRS) / Inertial Navigation System (INS) in the same mechanical assembly. The instrument comes in three mechanical variants; two standard GyroUSBLs that differ by the use of the HPT component (GyroUSBL 8084-000-0445 and […]
The Kongsberg cNODE Maxi is the largest members of the cNODE transponder family. The cNODE Maxi design is very modular and covers a large range of applications with its variety of different transducers, internal and external sensors, housing materials and other add-on functions. New configurations and software can easliy be downloaded from the Transponder Test and Configuration […]
The RTS LEVEL is a high-precision subsea inclinometer for ROVs and divers. By utilizing technology from the RTS TEXT subsea display the unit delivers unparalleled visibility and is capable of 70+ hours of continous subsea operation per charge cycle. The unit also features an optional external input which can interface up to two sensors. The […]
Based on the technology of the Gen 5 MUX, RTS now introduces the Gen 5 OCTO Multiplexer. The OCTO features a significant reduction in size and weight while still supplying five channels of high speed serial communication and three channels of 10/100 Mb ethernet through a single-mode fiber. The rugged yet compact 2000 MSW rated […]
Based on the RTS PPS Distribution Panel, the RTS PPS Box is a highly compact and robust solution for distributing GPS timing signals to survey spreads. The unit features low latency distribution of one timing telegram together with PPS pulse to seven separate outputs. The RTS PPS Box is typically used for time synchronization of […]
RAMSES is an acoustic synthetic baseline positioning system with self-contained computing, for simple real-time sparse array subsea navigation. Tightly coupled with iXBlue inertial navigation system (INS), it delivers extreme precision and robustness in challenging acoustic operational environment. Available in MF and LF versions (medium frequency for most applications and low frequency for ultra-long range applications), […]
The GP340, one of the market-leading radios in Motorola’s Professional Series, is a simple communication solution for portable users requiring a high-quality radio. The GP340 keeps users in touch; increasing efficiency and productivity. The radio offers essential functionality and security features to protect users working alone or remotely. With option board capability and a wide range of accessories available within the Professional […]
The Hammerhead wide angel colour zoom camera is used as main camera on work class ROVs. Praised by major operated wold wide of being a reliable and professional wide angle zoom camera. The Hammerhead Shark has 60⁰ wide angle lens and 18x optical zoom. Giving high quality video images and good control options by using […]
The Bowtech Products SURVEYOR-HD PRO ultra-wide angle underwater HDTV camera is designed to provide the viewer a greater angle of view, from the standard Surveyor HD, whilst remaining compact and very competitively priced. The camera is ideal for ROV inspection tasks, scientific observation and broadcast applications. Video output is available as HD or HD-SDI over […]
The Imenco SeaLED 20 miniature high output subsea light for diverse/small ROV/tools and inspection points. Fitted with the latest high quality LED producing an increased lifespan compared to the traditional Halogen and HID lights. SeaLED 20 can be delivered with different colour temperatures and lens angles. The light output is easily regulated from 0-100%.
Ideal for any ROV work and often used as a tool camera for close up inspections where illumination is required this colour camera is rated up to 4000msw has 10x optical zoom, 15 dimmable LED lights and RS232 control. Available in Duplex Stainless Steel.
The Wideband Sub-Mini 6 (WSM 6) is Sonardyne’s latest generation of versatile USBL transponders or responders that support WBv2 signals. The WSM 6 is designed for positioning ROVs, towfish and other mobile targets in water depths up to 4,000 metres. The compact and rugged design is based on the field proven WSM mechanics and is […]
The 3510 Ranger/Command, PAM Portable, has been developed to meet the harsh operating conditions associated with offshore marine operations. Housed in a rugged waterproof enclosure with a clear LCD display and splash proof key pad, it is ideal for on-deck operations. The 3510 has been designed to be a versatile tool for multi-transponder configuration and […]
cNODE® is a new family of transponders for underwater acoustic positioning and data link. They have more than 100 channels available, and can all be positioned by HiPAP® underwater positioning systems. Each underwater target to be positioned must have a transponder or a responder installed. The transponder operates acoustically while the responder requires a cable […]
The Bowtech Products EXPLORER LITE, low light level, high resolution, monochrome underwater CCD camera, is the ideal solution for extremely low light level, underwater viewing and navigation, yet still producing excellent images in high intensity illumination. The camera is manufactured with a high quality Hard Anodised Aluminium housing, rated to 2,000 metres operating depth as […]
The Bowtech Products MCVIS-1 miniature compact video inspection System is a portable splash proof control station for operation, viewing and recording of colour or monochrome underwater video cameras together with audio input and intensity control of a lamp. The MCVIS-1 comprises of a digital hard disk recorder with 32GB SD card drive. This produces noiseless […]
The Bowtech Products LCC-700-610 miniature high resolution monochrome underwater CCD camera is designed for use with our LED-540 lamp and fluorescent tracer dye, as part of our Leak Detection System. It is fitted with a 610nm filter to enable detection of the fluorescing dye. The cameras are manufactured with a high quality Titanium housing, rated […]
The Bowtech Products SURVEYOR-HD high definition underwater colour zoom camera, utilises Sony’s latest block camera incorporating 1/3 inch HD CMOS CCD giving exceptional picture quality, 10:1 optical zoom lens, as well as horizontal resolution of 800+ TV lines. Standard video output is component; however HD-SDI and fibre output are also available. A unique feature of […]
The Bowtech Products SURVEYOR-SD underwater colour zoom camera has the optional benefit of hand-held remote control. It utilises Sony’s ExView HADTM CCD technology, delivering exceptional picture quality, with a 36:1 optical zoom lens and a 12x digital zoom, as well as a horizontal resolution of 550 TV lines, all within a 4,000 metre rated high […]
CCTV – OCN 100 EXDE – Hazardous Zone 1, Mini Colour Camera The compact EExde miniaturized camera housing is manufactured in stainless steel (316L). Ingress protection is minimum IP66. Stainless steel swivel head bracket available as an option. The camera station is delivered complete with gland, sunshield and thermostatically controlled heating element. The […]
Teledyne Benthos underwater acoustic modems are used in worldwide subsea applications and are the only modems available in a combined modem/acoustic release configuration. Reduce the umbilical clutter by making any subsea sensor a wireless sensor for shallow or deep water applications. OEM configurations are available.
The BV4100 is a light weight tripod and a pan and tilt combination used for a 2D forward looking sonar in fixed position real time monitoring. The BV4100 is easily one person deployable from surface vessels, piers or docks. The simplicity and portability of the BV4100 makes the ideal tool for quick inspections and searches […]
Compact, easy to install and quick to set up, the SeaBat 7111 helps you get your survey started with minimal planning and preparation. Housed in a lightweight cradle, the SeaBat generates hi-res hydrographic charts that beat international standards down to 1,000 metres below sea-level. Switching between equidistant and equi-angular beam spacing gives you soundings that […]
The SEALCAST™ urethane housing is durable and is tank or externally mounted. Excellent for deep water surveys.
The Echotrac MKIII is the only sounder on the market offering you the choice of either a high resolution thermal paper recorder or a full-sized high bright color LCD chart in interchangeable module format. Both high and low channels feature frequency agility, enabling the operator to precisely match the transceiver to almost any existing transducer. […]
Specifically designed for work in less-than-ideal circumstances on small survey boats and inflatable watercraft, the HydrotracT offers compact portability and the confidence of knowing you’re using an Odom product. It is completely waterproof and comes equipped with the same advanced features you’ve come to trust and depend on in Odom echo sounders.
The M42 houses Odom’s best selling dual frequency transducer. Compatable with any hull material, it is best mounted on a fairing. Durable and reliable.
Completely designed and manufactured within the Teledyne Marine group, the new MB1 multibeam echo sounder is designed to meet the needs of hydrographic professionals that are looking for a low cost yet high performance swath sounder. Sounding Performance Using both amplitude and phase bottom detection, MB1 is capable of sounding a swath of up to […]
T-count is a reliable and accurate system for measuring the length of cable passing over a snatchblock. Designed to overcome the unreliability of systems using a deck lead, a radio link is used to display the count on an IBMT compatible PC, or the optional hand-held receiver. This innovative approach allows the operator moreconfidence when […]
The Hytek Cable Counter is a reliable and accurate system for measuring the length of cable or umbilical passing over the snatch-block sheave wheel. Counts up to 9999 meters in 1 metre increments.
Explorer is the world’s smallest, lightest, and most efficient high-sensitivity total-field magnetometer. That’s a lot of punch for a mag that packs so light. Explorer is the smallest, lightest total field mag out there! At a mere 3.8 kgs (8.5lbs) for the mag and 6 kgs (13 lbs) for a 50m (164 ft) tow […]
The most reliable magnetometer you’ll ever meet. Unfailing data, durable hardware and an easy going disposition make SeaSPY a mag you can count on. SeaSPY is a pulsed Overhauser magnetometer that measures the ambient magnetic filed using a specialised branch of nuclear Magnetic Resonance technology, applied specifically to hydrogen nuclei.
The Squid 2000 is intended for high resolution applications with low electrical power input and high penetration. It is stable under tow and can be easily adjusted for array depth for the best possible pulse shape.
The Squid 500 Sparker is a compact sound source that is affixed to a high voltage cable. It is used to obtain better penetration of seabed profiles when geological conditions are difficult. The Squid 500 Sparker operates well at 200-600 Joules and can be fitted with different electrode clusters for a variety of operational requirements.
GeoAcoustics GeoPulse is the survey industry’s industry standard Sub-Bottom Profiler system. Its proven success is due to its reliability, ruggedness, ease of operation and flexibility. Sub-Seabed structures are delineated using reflexions from a selectable single frequency multi-cycle high power signal, which is transmitted from an over-the-side, towed or hull mounted platform. The signal is processed […]
The EdgeTech 3200 Sub-bottom Profiling System is a wideband Frequency Modulated (FM) sub-bottom profiler utilizing EdgeTech’s proprietary Full Spectrum CHIRP technology. The 3200 generates high resolution images of the sub-bottom stratigraphy in oceans, lakes, and rivers and provides penetration of up to 200m. The 3200 comes available with a choice of three stable, low […]
No matter how much raw data has been collected from the survey site, it’s the results that your client values. When budgets get tighter, survey tasks become ever more time-critical and the process of interpreting acquired data must be as quick and easy as possible. Coda GeoSurvey Productivity Suite integrates the tasks of analysing, […]
Survey Engine Seismic+ is a ‘next generation’ 2D seismic data processing, interpretation and reporting application for the marine survey industry. Built on the years of experience that have made CodaOctopus’ software solutions a market leader at the heart of geophysical operations worldwide, Seismic+ brings survey tools up-to-date with the latest database and GIS technology. […]
The DA4G™ series of acquisition systems from the CodaOctopus:GEO family provides high quality, robust and reliable data acquisition from the latest digital and analogue sidescan sonar and sub-bottom profiler sensors. DA4G is the 4th generation of our successful DA series™ and is built on twenty years of knowledge, experience and innovation in supplying unparalleled […]
The all-new Coda GeoSurvey DAseries acquisition system is available for all sidescan sonars and sub-bottom profilers including the latest digital sonars and popular analogue systems. Building on more than 12 years of experience as a leader and innovator in the field of geophysical acquisition, Coda GeoSurvey is the system of choice for many of the […]
GeoAcoustics GeoPrinter is a highly reliable, all-purpose image printer that provides fast, high quality photographic images. Images are recorded on a choice of thermal fibre-based paper, or plastic-based transparent film. The printed images are 25.6 cm (10.1 inches) in width by any length up to 45.7 m (150 ft) and feature 256 shades of grey […]
HYPACK® is the most widely used hydrographic software package in the world. Here’s why. HYPACK® provides all of the tools necessary to complete your hydrographic, side scan and magnetometer survey requirements. With over 4,000 users around the world, HYPACK® provides you with the tools necessary to meet almost any hydrographic survey requirement. It […]
Digiquartz® Depth Sensors provide the ultimate precision in water level measurements. Typical application accuracy of 0.01% is achieved even under difficult environmental conditions. Desirable characteristics include excellent long-term stability, 1 x 10–8 resolution, low power consumption, and high reliability. The remarkable performance of these depth sensors is achieved through the use of a precision […]
The SBE 39-IM is a high-accuracy temperature (pressure optional) recorder with built-in Inductive Modem. The IM system provides reliable, low-cost, real-time data transmission for up to 100 IM-enabled instruments, using plastic-coated wire rope (typically 3 x 19 galvanized steel) as both the transmission line and mooring tension member. IM instruments clamp anywhere along the rugged […]
The Teledyne CDL MiniTilt is an OEM, surface or subsea Pitch and Roll sensor. It provides an accuracy of 0.05 degrees in both axes over the full 360 degree range. The unit can be provided in a surface or subsea (3,000m or 6,000m rated) package or can be supplied in an accurately machined mounting frame […]
The scanning sonar can be utilised to monitor the diver operation. In most situations the sonar can be deployed (on a tripod or weighted line) from the side of the support vessel, and positioned to scan the work area.
The EdgeTech 2200 and 2205 are compact, extremely flexible and configurable sonar system for integration on 3rd party underwater vehicles. They are specially designed for installation and use on Unmanned Underwater Vehicles (UUVs / AUV), Remotely Operated Vehicles (ROVs), Unmanned Surface Vehicles (USVs), and other hosted platforms. This modular unit can be configured, based on […]
EdgeTech’s 2400 Series is a fully integrated combined side scan sonar & sub-bottom profiling system designed for deep water operation in depths up to 6,000m. The 2400 can be completely configured by the user to best suit the applications at hand. The system comes with a dual simultaneous frequency side scan sonar with a […]
The 4125 utilizes EdgeTech’s Full Spectrum® CHIRP technology, which provides higher resolution imagery at ranges up to 50% greater than non CHIRP systems operating at the same frequency. This translates into more accurate results and faster surveys, thus cutting down on costs. Two dual simultaneous frequency sets are available for the 4125 depending on […]
The 4200 Series is a versatile side scan sonar system that can be configured for almost any survey application from shallow to deep water operations. The 4200 utilizes EdgeTech’s Full Spectrum® CHIRP technology to provide crisp, high resolution imagery at ranges up to 50% greater than non-CHIRP systems; thus allowing customers to cover larger areas […]
The 6205 utilizes EdgeTech’s next generation bathymetric technology to provide an enhanced and fully integrated, swath bathymetry and dual frequency side scan sonar system. The 6205 produces real-time, high resolution, three dimensional (3D) maps of the seafloor while providing co-registered simultaneous dual frequency side scan imagery.The 6205 uses ten receive element transducers and one discrete […]
The 2000 Series combines EdgeTech’s highly successful line of side scan sonars and sub-bottom profilers into one fully integrated system. The combined side scan sonar and sub-bottom profiling system comes in a choice of three different towfish: 2000-CSS, 2000-DSS and 2000-TVD. The CSS comes with a low frequency 500 Hz – 12 kHz sub-bottom profiler […]
Deployed from a patrol boat, Teledyne BlueView’s BV3100 is ideal for search and recovery operations, dive team situational awareness, and diver vectoring. It is also an effective means of harbor bottom inspection as well as diver and underwater IED detection. The BV3100 uses Teledyne BlueView’s 2D forward looking sonar mounted to a digital pan and […]
GeoAcoustics GeoSwath Plus offers very efficient simultaneous swath bathymetry and side scan seabed mapping with accuracies that have been shown to exceed the IHO Standards for Hydrographic Surveys. The applied phase measuring bathymetric sonar technology provides data coverage of up to 12 times the water depth, giving unsurpassed survey efficiency in shallow water environments. The […]
The most versatile 3D ocean current meter available. Aquadopp 3D current meterThe Aquadopp is probably the most versatile single-point current meter on the market. It is cost-effective, robust and has a wide range of applications. The system electronics integrates accurate Doppler velocity measurements with standard sensors such as temperature, pressure, tilt, and compass. It is […]
The 3000 m Aquadopp is designed for deployments down to 3000 m and it has all the capabilities of the standard Aquadopp. It is a modern, yet well-proven instrument and it is undoubtedly the most versatile single-point current meter on the market. Relative to the standard system, it has a larger diameter (about 84 mm […]
The 6000 m Aquadopp is “the big brother” in the line of Aquadopp models. The all-titanium mechanical housing is built to last at great ocean depths. The overall design is the result of a testing and verification process that has included many of the world’s largest oceanographic institutions. Rugged and resistant, the 6000 m model […]
The MIDAS ECM is a highly versatile point current meter, designed with durability and ease of deployment in mind. Valeport’s latest electronics architecture allows multiple additional sensors, and a variety of communications options, making it one of the few multiparameter current meters that allows real time operations over several thousand metres of cable, as well […]
A low cost, lightweight alternative to larger flow meters, ideal for use in applications where the superior durability and depth rating of Valeport’s larger meters is not necessary. Utilising the standard Valeport 125mm diameter impeller, the Model 106 features speed and direction parameters as standard, with further options of temperature and depth. Data (logged or […]
The Model 803 is designed specifically for use on ROVs and other underwater vehicles, providing real time relative water velocity information for pilots. It may be fitted to ROVs to provide actual through the water speeds, or fitted to Tether Management Systems to give measurement of local flow conditions. Measurements are updated every second and […]
The core of the system is a digital pressure and temperature logger, built into a stainless steel pressure housing with viewing window, suitable for immersion to 4000 metres of seawater. Then assembled with ROV Operable valves and client specified hotstab / connection arrangement. (Frame is customizable). The Data logger, range 0 to 700bar, up to […]
The MIDAS SVP is the new name for Valeport’s renowned Model 650 Mk2 Sound Velocity Profiler, and it gives the most accurate Sound Velocity Profiles currently possible. As well as using the world leading digital time of flight sound speed sensor, this instrument also has a ±0.01% pressure sensor, and features Valeport’s synchronised sampling technique […]
The miniSVS Sound Velocity Sensors use state of the art digital “time of flight” technology to provide the lowest noise, highest accuracy, best resolution sound velocity data available. Small size and a choice of sensor lengths down to just 25mm make the sensor suitable for a variety of applications, and the optional pressure or temperature […]
Vaisala BAROCAP® Digital Barometer PTB220 is designed for measurements in a wide environmental pressure and temperature range. The barometers are ideal to be used e.g. as ship barometers, as transfer standards in weather stations and as replacements for mercury barometers. The PTB220 barometers feature extremely high accuracy. Class A barometers are fine adjusted and calibrated […]
Vaisala BAROCAP® Digital Barometer PTB330 is a new generation barometer, designed for a wide range of high-end atmospheric pressure measurement.
The TideMaster is a small, cost effective Water Level Recorder, specifically designed for applications where the user requires an accurate record of water height, but with the added option of meteorological data via a ultrasonic wind speed and direction sensor. Suitable for use in fresh or salt water, the TideMaster can be deployed for up […]
The MIDAS WLR replaces the popular Model 730T as Valeport’s Water Level Recorder / Seabed Tide Gauge. Designed for long or short term deployments in offshore environments, or locations where a traditional shore based tide gauge is impractical, the MIDAS WLR may be moored in line or to the seabed. The standard instrument is fitted […]
The miniTIDE is a small Tide Recorder, designed for short term underwater deployments. Fitted with a 0.01% temperature compensated piezo-resistive cell, the miniTIDE will record high accuracy pressure data for a period of 1 month at a 10 minute sampling interval, using a single alkaline C cell. This makes it ideal for use in short […]
The VRS-20 is a pulsed k-band radar level sensor developed by Valeport to work seamlessly with the TideMaster tide logger, operate standalone with optional integrated GPRS telemetry or interface to a third party data logger. Versatile and simple to install, the VRS-20 addresses a number of the issues traditionally associated with water level measurement. Non-contact […]
The Directional Waverider hardly needs any introduction: it is the world’s standard for measuring wave height and wave direction. Its success is due to the proprietary well-proven and accurate Datawell stabilized platform sensor, enabling wave height measurements by a single accelerometer. For the wave direction, direct pitch and roll measurements are performed needing no integration. […]
The Gen 5 MUX has rapidly manifested itself as the preferred high end ROV multiplexer solution in the industry. The MUX covers the increasing demand for accurate, flexible and robust subsea data transfer combined with user-friendly interfacing. Offered models and options allow for supplementary functions such as Composite and HD video, fibre assembly adaptors and channel customization. The […]
The Gen 5 MUX has rapidly manifested itself as the preferred high end ROV multiplexer solution in the industry. The MUX covers the increasing demand for accurate, flexible and robust subsea data transfer combined with user-friendly interfacing. Offered models and options allow for supplementary functions such as Composite and HD video, fibre assembly adaptors and channel customization. The […]
The Gen 5 MUX has rapidly manifested itself as the preferred high end ROV multiplexer solution in the industry. The MUX covers the increasing demand for accurate, flexible and robust subsea data transfer combined with user-friendly interfacing. Offered models and options allow for supplementary functions such as Composite and HD video, fibre assembly adaptors and channel customization. The […]
Sonardyne’s range of Super Sub-Mini Transponder/Responders (SSMs) represent the latest design developments in the acoustic positioning of ROVs, towfish and other subsea targets. The Type 7970 Super Sub-Mini is designed for deepwater applications up to 4,000 metres and has a highpower directional transducer with an acoustic output comparable to Sonardyne’s most powerful Compatt transponders. For […]
Sonardyne’s range of Super Sub-Mini Transponder/Responders (SSMs) represents the latest design developments in the acoustic positioning of ROVs, towfish and other subsea targets. The Type 7973 Super Sub-Mini isdepth rated to 1,000 metres and has an omni-directional beam pattern that gives a wide area of acoustic coverage. For improved positioning accuracy, a built-in pressure transducer […]
WSM is our previous generation release transponder which has now been replaced by WMT 6. Although the WSM transponder is no longer available to purchase, Sonardyne still offers full after sales technical support including spares, repairs and servicing for this product. The Type 8070 Dual Release Wideband Sub-Mini (WSM) is a 4,000 metre rated transponder/ […]
Ranger system is a high performance, survey grade Ultra-Short BaseLine (USBL) acoustic positioning system designed for Dynamic Positioning (DP) reference and ROV/towfish tracking operations. The system incorporates Sonardyne Wideband® acoustic signal technology to enable seamless multi vessel ‘SIMOPS’ capability ensuring no vessel down time. It is recognised as the optimum solution for deep water DP […]
Scout USBL is a complete vessel based acoustic positioning system designed for tracking divers, ROVs and towfish in waters up to 1,000 metres. The system calculates the position of a subsea target by measuring the range (distance) and bearing (heading) from a vessel mounted transceiver to a small acoustic transponder fitted to the target; a […]
The SBE 19plus V2 (Version 2) SeaCAT Profiler measures conductivity, temperature, and pressure (depth) and provides high accuracy and resolution, reliability, and ease-of-use for a wide range of research, monitoring, and engineering applications. The pump-controlled, TC-ducted flow configuration minimizes salinity spiking caused by ship heave and allows for slow descent rates without slowing sensor responses, […]
The MIDAS SVX2 is the latest version of Valeport’s unique instrument. Recognising the conflict faced by users requiring the superior Sound Velocity data from an SVP, but still needing the Salinity and Density data from a CTD, the MIDAS SVX2 combines both technologies to give the best of both worlds. Now fitted with a 0.01% […]
The MIDAS CTD (previously known as the Model 606) is Valeport’s premier CTD Profiler. High accuracy sensors (including ±0.01% pressure) and robust titanium design allow reliable operation to 6000m depth, under the harshest conditions. It also features truly synchronised sampling to ensure that all sensors are sampled at exactly the same point during a profile. […]
The MIDAS CTD+ is a revolutionary Multiparameter CTD, with a wide choice of standard sensors. Featuring Valeport’s latest 400 Series electronics, the CTD+ will sample all fitted sensors at exactly the same instant, at up to 8Hz. Advanced setup software allows a variety of sampling regimes including burst modes, delay starts, and conditional sampling. With […]
ORTs and DORTs are controlled using a frequency band specific Lightweight Command Unit (LCU) which consists of an over-the-side dunking transducer connected either to a splash-proof handheld terminal or, via supplied software, to any PC. The Type 7663 unit is a Medium Frequency LCU for commanding ORTs whilst the Type 7667 LCU is a Low […]
Oceanographic Release Transponders (ORTs) and Deep Oceanographic Release Transponders (DORTs) are tough, reliable acoustic releases designed for deployment in either 2,000 metres or 6,000 metres of water. The units are commonly used to moor oceanographic instrument strings on the seabed for periods of up to 36 months. However, their compact size allows them to be […]
In order to increase the Safe Working Load (SWL) of a standard ORT, DORT, Heavy Load DORT, P-DORT and Heavy Load Compatt 5, Sonardyne offer a range of heavy duty release frames. The frames act as a load amplifier so that only a fraction of the mooring load passes through the acoustic release. Applications include: […]
LRTs, LATs, Coastal Transponders and TZ/OBC Transponders are commanded using a Type 7967-000-01 transponder deck unit. The system comprises of a deck unit and dunking transducer supplied with 10 metres of cable. The deck unit is used initially to program the acoustic identity of the transponder, test the transponder and, in the case of the […]
The Type 7986 Lightweight Release Transponder (LRT) has been developed from transponders capable of accurately positioning hundreds of seismic receiver nodes. It has both receive and transmit functions, unlike similar low-cost release transponders, enabling accurate slant ranges to be measured, release actuation to be confirmed and its position to be accurately determined. The LRT is […]
Teledyne Benthos underwater acoustic modems are used in worldwide subsea applications and are the only modems available in a combined modem/acoustic release configuration. Reduce the umbilical clutter by making any subsea sensor a wireless sensor for shallow or deep water applications. OEM configurations are available.
For long-range, long-term deployments, the Long Ranger is the best choice for collecting detailed data on seasonal and annual current structure fluctuations for scientific research and offshore oil and gas applications. The highly reliable Long Ranger delivers the precision accuracy you require, combined with the dependability of RDI’s proven Workhorse products. Hundreds of Long Ranger […]
The self-contained Sentinel is Teledyne RD Instruments’ most popular and versatile Acoustic Doppler Current Profiler (ADCP) configuration, boasting thousands of units in operation in over 50 countries around the world. By providing profiling ranges from 1 to 165m, the high-frequency Sentinel ADCP is ideally suited for a wide variety of applications. The Sentinel also offers […]
The Type 8305 AMT is a long-endurance Compatt 6 based transponder that is extensively used for subsea survey tasks and is capable of autonomously acquiring acoustic ranges and sensor data without surface control. The data is time-stamped and logged internally for recovery via the integrated high-speed acoustic telemetry modem. This autonomy allows measurements to be […]
Pocket Test Terminal (PTT) is a new truly portable Compatt 5 test tool. Running on a dedicated iPAQ PDA platform, the PTT software offers all the main features of the PC-based Compatt 5 Test Terminal software but from a small, portable, splash proof device. It is therefore ideal for taking on to the back deck […]
Compatt 5 Midi is our previous generation tracking transponder which has now been replaced by Compatt 6. Although the Compatt 5 transponder is no longer available to purchase, Sonardyne still offers full after sales technical support including spares, repairs and servicing for this product. Faster set up and calibration greater equipmentutilisation reduced risk these are […]
Compatt 5 is our previous generation LBL transponder which has now been replaced by Compatt 6. Although the Compatt 5 transceiver is no longer available to purchase, Sonardyne still offers full after sales technical support including spares, repairs and servicing for this product. Faster set up and calibration, greater equipment utilisation and reduced risk. These […]
The Compatt 6 transponder is fully compatible with all 6G® equipment and Sonardyne’s latest 6G® LBL and USBL systems. Compatt 6 offers significant time saving using faster and more robust Sonardyne Wideband®2 acoustic ranging and telemetry protocols. This makes any system operating with Compatt 6 significantly easier to operate therefore de-risking operations, reducing vessel time […]
The Data Fusion Engine is the heart of the system and is an integrated PC and navigation controller used to interface peripheral equipment such as GPS and attitude sensors, in addition to providing dedicated interface and power to transceivers. This ‘one-box’ solution is designed to meet a complete onboard hardware requirement for any acoustic operation, […]
Sonardyne’s range of subsurface floatation collars enable acoustic navigation and positioning transponders to be deployed, moored on the seabed and then recovered to the surface. The floats are compatible with all Sonardyne’s latest generation Compatt 6 and DPT Wideband transponders as well as previous generation Mk 5 & 4 Compatts. They can be used with […]
The Type 8020 Navigation Controller Unit (NCU) forms part of a Data Fusion Engine, a ‘one-box’ solution designed to meet the complete on-board requirements of any acoustic operation. The NCU is the interface between the in-water acoustic instruments, sensors and the Navigation Computer which runs the acoustics positioning software. In addition to accurately time stamping […]
ROVNav 5 is our previous generation transceiver which has now been replaced by ROVNav 6. Although the ROVNav 5 tranceiver is no longer available to purchase, Sonardyne still offers full after sales technical support including spares, repairs and servicing for this product. ROVNav 5 is a highly configurable, tri-band acoustic transceiver designed to support a […]
ROVNav 6 is a 6G® Wideband®2 ranging and telemetry Long BaseLine (LBL) and telemetry transceiver specifically designed for installation on work class ROVs. Its high power output and Sonardyne Wideband®2 signal processing offers improved range and acoustic performance in challenging conditions such as on noisy vehicles or in multipath environments. ROVNav 6 is also a […]
The RTS Green Line Laser produces a straight green line with uniform intensity over a long range, made possible by its wavelength enabling maximum water penetration. Aligned laser setup provides excellent accuracy for close range inspection and measurements. The RTS Green Line Laser is designed to ensure exceptional stability under varying and challenging operation conditions.
The 2520 PAM Tester/Charger has been designed to be a highly versatile and invaluable operator tool. It is used to test and charge AAE beacons, and test those from other manufacturers. It operates in the MF and LF frequency band. The multi-function deck set is used to: Check transponders, responders and pingers prior to use, […]
The Mini SSBL transponders (MST) are medium frequency mini-transponders. The MST transponders are to be used with the following underwater positioning and navigation systems: HiPAP system HPR series It is to be used for applications where a small and lightweight unit is required. A MST transponder is delivered with a moulded protective plastic coating. Uncoated units are available as an […]
The Seapath 200 provides highly accurate, real-time heading, attitude and position information by blending the best characteristics of sensor-based inertial navigation and GPS continuous position update technologies. High-rate motion data obtained from the system’s IMU (Inertial Measurements Unit) and precise position data from two, fixed baseline GPS carrier-phase receivers are integrated in a Kalman Filter […]
POS MV 320, POS MV Elite and the POS MV WaveMaster are all tightly-coupled systems using Applanix’ unique approach to Inertially-Aided Real-Time Kinematic (IARTK) technology. The user-friendly, turnkey systems provide accurate attitude, heading, heave, position, and velocity data, representing the latest in state-of-the-art inertial/GPS technology. The systems maintain positioning accuracy under the most demanding conditions, […]
The Meridian gyrocompass is a product suitable for the ever-changing needs of a modern integrated navigation bridge system. This includes highly accurate performance with low cost of ownership and system flexibility. Due to the Meridian’s small size and fast settle time of less than 45 minutes, there are no limits to the type of vessel […]
The Meridian Surveyor boasts a wide range of interfaces to enable use on any marine vessel. The unit utilises a DTG gyro element which provides exceptional performance with accuracy unmatched by even the latest fibre optic designs. Unlike conventional spinning mass gyrocompasses, the Meridian Surveyor uses a dry tuned element (DTG) that removes the need […]
Enhanced GNSS heading and positioning technology with GLONASS. Precise marine and land applications demand the heading and positioning performance of the Vector™ VS131™ receiver making it ideal for professional machine control and navigation applications in any environment. The Vector VS131 utilizes all of the innovations of Hemisphere GNSS’ Crescent® Vector technology, offering a series […]
The I2NS™ integrates seamlessly with R2Sonic Wideband Multibeam Echosounder Systems providing accurate and robust geo-referencing and motion compensation for hydrographic surveys. The I2NS™ provides existing and new R2Sonic customers an industry proven, tightly coupled solution for vessel roll, pitch, heave, heading, position and velocity which is easy to set-up, operate and control through a monitoring […]
The Lodestar GyroCompatt (LGC) integrates Sonardyne’s Wideband® acoustic positioning and Lodestar Attitude and Hearing Reference Technology (in one small, highly versatile and robust instrument). This provides high update rate wireless attitude, heading, heave, surge, sway, pressure, SV and acoustic positioning of any subsea object. Compatible with USBL and LBL positioning systems, the Lodestar GyroCompatt product […]
The medium frequency transponders, the SPT 31x and MPT 31x series are the subsea and seabed elements of the Kongsberg Maritime underwater positioning and navigation systems. The transponder models have 56 channels for use with the HiPAP / HPR systems. Common for all the models are that they, on interrogation, replies with a single- or a multi-pulse response. This reply […]
Used in the survey and ROV industries, the sturdy device is used to float the transponder upright to the surface for recovery.
The TTC 400 has been developed to provide a quick and easy way to test and configure all applications on Kongsberg Maritime transponders, prior to sea deployment. The TTC 400 is based around a splash-proof, small (all in one) and portable unit. The unit is equipped with carrying handles. A small transponder on a cable, […]
